LED Lighting Guide: Types and Uses

Choosing LED lighting starts with understanding the space. A kitchen counter needs focused task lighting, an office needs comfortable overhead illumination, and a warehouse needs fixtures that deliver strong light from a high ceiling.

Whether you are replacing lamps, updating your business, or planning an installation, New Era Electric Supply carries LED fixtures, flexible lighting, drivers, controls, and mounting accessories for a variety of projects. This guide explains common options, where to use them, and what to check before purchasing.

Before Choosing Your LEDs

Start by identifying what the lighting needs to accomplish:

• General lighting: Illuminate a room or open area.

• Task lighting: Help people see clearly while cooking, reading, assembling, or working.

• Accent lighting: Highlight displays, artwork, shelving, or architectural details.

Many spaces benefit from a combination. In a kitchen, for example, downlights can provide general illumination while undercabinet LEDs light the work surface.

1. LED Flat Panels: Broad, Even Overhead Lighting

LED flat panels provide overhead illumination with a slim, clean appearance. They are commonly used in commercial interiors where consistent lighting and ceiling fit are important.

Common uses: Offices, classrooms, retail spaces, and other commercial interiors.

New Era carries:

• 2 × 2 LED flat panels: Including 40W and wattage- and color-selectable options.

• 2 × 4 LED flat panels: Including 72W and wattage- and color-selectable options.

Before purchasing, confirm the ceiling system, fixture dimensions, mounting requirements, light output, and dimming compatibility. Selectable models offer preset wattage and white-light color-temperature settings.

2. Recessed Downlights, Disk Lights, Cans, and Trims

Downlights and disk lights provide ceiling illumination with a compact appearance. Recessed projects may also require compatible housings and trims, depending on the fixture and installation method.

Common uses: Kitchens, hallways, living areas, offices, and retail interiors.

New Era carries:

• 4-inch LED downlights.

• 6-inch LED disk lights.

• 4-inch and 6-inch slim recessed trim, baffle, and gimbal options.

• AH Lighting 4-inch and 6-inch new-construction cans, including AH-A4 and AH-A7 LED IC-AT housings.

• AH Lighting A4/5CCT, A7/5CCT, and A7 Slim 5CCT models.

• MERD409 SM 4-inch recessed lighting.

Confirm the ceiling opening, available clearance, mounting method, and location rating. Match trims and light modules to the correct housing, and check the product’s insulation-contact and airtight ratings where required.

3. LED Tape and Neon Flex: Task and Accent Lighting

Flexible LED tape fits into compact spaces, making it useful for lighting counters, shelving, and architectural details. Neon flex offers a continuous illuminated appearance for decorative outlines and other accent applications.

Common uses: Undercabinet lighting, shelving, display cases, ceiling coves, and architectural accents.

New Era carries:

• 16-foot single-color COB LED tape rolls: Including 3000K, 4000K, and 5000K options.

• 16-foot CCT COB LED tape rolls.

• 33-foot LED neon flex tape: Top-view or side-view options.

• 33-foot RGB LED neon tape: Top-view or side-view options.

Choose the light output around the application. Task lighting needs enough illumination for the work surface, while accent lighting should complement the surrounding space.

For low-voltage products, match the power supply to the lighting’s voltage and total load. Check maximum run length, cutting instructions, bend limits, mounting requirements, and compatible controls.

4. LED Flexible Sheets: Backlighting and Illuminated Surfaces

LED sheets distribute light across a broader surface than a narrow tape strip. They can be useful for projects that require backlighting behind compatible translucent materials.

Common uses: Displays, signage, decorative panels, and compatible backlit surfaces.

New Era carries:

• 1 × 2-foot single-color LED sheets.

• 1 × 4-foot, 22W LED sheets: Single-color and CCT options.

• 2 × 4-foot CCT LED sheets.

• 9 × 19-inch single-color LED sheets.

• 9 × 18-inch, 2700K, 24V LED sheets.

• 12 × 24-inch, RGBW, 24V LED sheets.

Confirm sheet dimensions, voltage, power requirements, and manufacturer-approved cutting and mounting methods. For backlighting, test the spacing and material together to check for visible hotspots before completing the installation.

5. Linear LED Strip Fixtures: Utility and Work-Area Lighting

Rigid linear LED strip fixtures are complete fixtures used to illuminate work areas and utility spaces. They serve a different purpose from flexible LED tape.

Common uses: Garages, workshops, stockrooms, utility rooms, and commercial work areas.

New Era carries:

• 4-foot narrow and slim LED strip fixtures.

• 4-foot wattage- and color-selectable LED strip fixtures.

Select fixtures around the mounting height, layout, and work being performed. Confirm light distribution, installation requirements, and the appropriate location rating.

6. LED Tubes: Updating Existing Linear Fixtures

LED tubes are commonly used to update fluorescent lighting. Matching the tube’s length is only part of the selection process; the fixture’s electrical configuration also matters.

Common uses: Offices, garages, workshops, and commercial interiors.

New Era carries:

• 4-foot T8 LED lamps with selectable wattage and color temperature.

Before purchasing, confirm the lamp’s installation type:



Do not assume a tube’s installation type from its size or selectable settings. Have a qualified electrician evaluate any conversion that changes fixture wiring.

7. High Bays and Outdoor Area Lighting

High-bay fixtures serve spaces with higher mounting positions, while outdoor area fixtures direct light across exterior spaces.

Common uses: Warehouses, production areas, parking areas, and building grounds.

New Era carries:

• 200W UFO LED high-bay fixtures.

• 30W and 50W LED shoebox area lights.

For high bays, consider ceiling height, fixture spacing, light distribution, and the work being performed. For outdoor lighting, check mounting requirements, weather suitability, shielding, and aiming to limit glare and unwanted light spill.

8. Emergency and Exit Lighting

Emergency and exit lighting supports visibility and wayfinding during a loss of normal power. Product selection depends on the building and installation requirements.

Common uses: Commercial exits, corridors, and other required locations.

New Era carries:

• Bi-color LED exit lights with emergency-light combination units.

Confirm the available sign-color settings, backup-power specifications, mounting options, and applicable project requirements before selecting a unit.

9. Magnetic Track Rails, LED Channels, and Mounting Accessories

Mounting components help create a complete lighting installation. Track rails support compatible lighting modules, while LED channels help mount and protect suitable tape lighting.

Common uses: Retail displays, architectural accents, shelving, and linear lighting installations.

New Era carries:

• 42-inch magnetic recessed track rails.

• 82-inch magnetic recessed track rails.

• 8-foot LED channels with a listed 0.66-inch dimension.

Confirm the full channel dimensions and tape fit before purchasing. For magnetic track systems, verify compatibility among the rail, lighting modules, power supply, and accessories.

10. LED Drivers, Transformers, and Controllers

Low-voltage LED projects need a compatible power supply. Dimming, tunable-white, and color-changing installations may also require dedicated controls.

Common uses: LED tape, flexible sheets, neon flex, and other compatible low-voltage lighting systems.

New Era carries:

• 96W, 100W, and 200W LED drivers listed as Class 2 with 5-in-1 functionality.

• 150W and 300W transformer/driver options listed as Class 2.

• Additional Class 2 LED driver options.

• 5-in-1 Wi-Fi LED controllers rated at 30A.

Match the driver’s output voltage and capacity to the lighting system. Confirm supported dimming methods, controller compatibility, and the manufacturer’s per-output ratings and load limits. For controllers, check both total and per-channel limits.

Understanding Selectable and Color-Changing LEDs

These terms describe different lighting capabilities:

• Selectable white: Choose from preset white-light color temperatures, often using a switch on the product.

• Tunable white: Adjust white light from warmer to cooler tones through compatible controls.

• Dim-to-warm: White light becomes warmer as it dims.

• RGB: Combines red, green, and blue channels to create colored lighting.

• RGBW: Adds a dedicated white-light channel to RGB lighting.

For products labeled CCT, confirm whether the model offers preset selection or adjustable white light through a controller. Select the controls together with the lighting system.

Specifications to Check Before Buying

Lumens and Watts

Lumens describe light output; watts describe power consumption. Compare lumens when choosing brightness. Approximately 800 lumens is a common replacement target for a traditional 60W incandescent bulb.

Color Temperature

Color temperature is measured in kelvin (K). Lower values appear warmer; higher values appear cooler.

As a starting point, consider 2700K–3000K for a warm atmosphere and 3500K–4000K for a more neutral appearance. Evaluate a sample in the actual space before ordering a large quantity.

Color Rendering

The Color Rendering Index, or CRI, describes how faithfully a light source renders colors compared with a reference source. CRI 90 or higher is useful when the appearance of merchandise, finishes, or other colors matters.

Compatibility and Serviceability

Confirm voltage, driver requirements, dimming method, location rating, and mounting details. For integrated LED fixtures, ask whether the driver or light engine can be replaced and review the warranty.

Bring the Right Information to the Counter

To help New Era’s staff identify suitable options, bring:

• Photos and model numbers of existing fixtures, lamps, ballasts, and controls.

• Room dimensions, ceiling height, and the intended use of the space.

• Preferred brightness and color temperature.

• Details about moisture, outdoor exposure, or other environmental conditions.

• Quantities and project timing.

For California lighting projects, review applicable energy-code and local permit requirements before selecting materials.

NEW ERA ELECTRIC SUPPLY: Lighting and Components for Your Project

From LED flat panels and recessed lighting to flexible sheets, COB tape, drivers, and controls, New Era Electric Supply carries options for residential and commercial lighting projects.

Our counter staff can help compare available products, identify compatible components, and clarify missing specifications. Contact the store ahead of larger or specialized orders to confirm models, quantities, and availability.

Visit: 1630 Flower Street, Glendale, CA 91201
Call: 818-338-2288
Email: sales@eraesupply.com
Website: NewEraElectricSupply.com

Follow manufacturer instructions and confirm project-specific installation and code requirements with the appropriate professional.
